1. Defect-Prevention Architecture
Most deep drawing failures occur due to inconsistent friction. We combat this through:
Active Lubrication Reservoirs: Precision-machined micro-channels that ensure constant oil film integrity during deep strokes.
Optimized Punch Radii: Scientifically calculated curves that distribute stress evenly, preventing localized thinning at the cup base.
2. Heavy-Duty Metallurgy & Coating
To extend the maintenance interval, we employ a "Triple-Layer" surface strategy:
Base: High-chrome tool steel for core toughness.
Interface: Plasma nitriding to increase surface fatigue resistance.
Contact: Specialized PVD coatings (AlCrN or similar) to provide a low-friction barrier against galling.
3. Streamlined Export Workflow for B2B Clients
We recognize that international buyers need reliability above all else:
FEA Simulation Proof: We provide a digital report showing the potential stress zones and thinning percentages before we start manufacturing.
Standardized Components: We use internationally recognized brands (DME, MISUMI, DANLY) for pins and bushings, making it easy for you to source replacements locally.
Comprehensive Video Archiving: A complete video log of the "T1 to Final Trial" is included, providing transparency for your engineering team.
| Operational Metric | Performance Standard |
| Tooling Accuracy | Linear tolerance within 0.01mm |
| Steel Grade Selection | DC53, D2, or High-Vanadium PM Steels |
| Cycle Speed | Optimized for 15-60 SPM (Strokes Per Minute) |
| Material Compatibility | SPCC, SUS304/316, 5052 Aluminum, Titanium |
| After-Sales Support | 24-Hour Remote Engineering Consultation |
