Structural features of progressive die stamping die:
1. The mold is composed of an upper mold, a lower mold and a mold sleeve, and is guided by a guide post;
2. The upper mold has an upper mold fixing plate equipped with a convex mold and a screw connected to the upper template;
3. Insert two semi-conical concave molds into the concave mold sleeve with tapered hole, with a cavity hole in the middle, and two semi-circular concave molds with two positioning pins for positioning;
4. The lower mold is composed of a lower mold fixed plate with a core and another core;
5. The unloading part is composed of ejector pins and ejector pads. After the parts are formed, the upper mold is first opened with a special mold unloading work, and then the ejector pins are used to eject the two semi-conical concave molds out of the mold. The product can be taken out by separating the progressive mold.
|
Product Details |
Company Information |
||
|
Product name |
Progressive die stamping die |
Main products |
Stamping die Stamping parts |
|
Application |
Manufacturing industry |
Productive forces |
Stamping: 2-3 million pieces/month |
|
Material |
ST14-ST16S |
Mould: 40-60 sets/month |
|
|
Standard Parts |
MISUMI |
Related certificates |
ISO9001 |
|
Template flatness |
+/-0.005mm |
Package |
According to customer requirements |
|
Quantity |
1 set |
Application field |
Aviation, automobiles, home appliances, medical, hardware, construction |
