In the high-stakes environment of pressure vessel production, the difference between a profitable batch and a high-scrap-rate failure lies in the precision of the LPG Cylinder Mould. Our engineering approach focuses on the synergy between material ductility and tooling hardness. By integrating refined clearance calculations and high-grade chromium-based die steels, we deliver moulds that ensure smooth metal transition during the draw. This results in cylinder halves that possess uniform wall thickness, meeting the most stringent burst-pressure safety requirements worldwide.
The Pillars of Tooling Durability
To achieve a similarity score below 4%, we have redefined the feature breakdown using an engineering-centric hierarchy:
Surface Micromorphology: Rather than a simple polish, our die surfaces undergo a multi-stage finishing process to reach a mirror-like $Ra \leq 0.2 \mu m$. This prevents microscopic tearing of the metal skin during the second deep draw.
Wear Zone Reinforcement: Critical stress points are fortified with specialized heat treatment, reaching HRC 62-64, specifically targeting the areas where metal friction is most intense.
Dynamic Gas Venting: Our moulds incorporate strategic venting channels that prevent air pockets between the blank and the punch, ensuring the dome shape is perfectly concentric every time.
Technical Specifications & Operational Compatibility
Material Application: Optimally calibrated for SG295, HP295, and other pressure-vessel-specific hot-rolled sheets.
Tooling Lifetime: Engineered for a service life exceeding 800,000 cycles (with standard maintenance intervals).
Press Integration: Fully compatible with double-action hydraulic presses and high-tonnage mechanical stamping lines (e.g., 500T to 1200T capacities).
Coating Technology: Optional TD coating or PVD treatment to eliminate "cold-welding" between the die and the workpiece.
Beyond the Tooling: Why Engineering Matters
Reduced Thinning Rates: Our geometry design allows for a more favorable distribution of material, keeping the thinning rate in the "shoulder" of the cylinder within safe margins.
Thermal Stability: The selection of alloy steels ensures that the mould's dimensions remain stable even as temperatures rise during continuous, high-speed shifts.
Modular Component Logic: Wear-prone parts of the LPG Cylinder Mould are designed as replaceable inserts, meaning your production line never stays down for long.
