Scientific Control of Metal Deformation
The success of a deep drawing operation is defined by how the material flows into the die cavity. Our tooling solutions incorporate advanced friction-management technology to ensure a consistent slip-rate.
Controlled Thinning: Our designs keep the wall thickness deviation within ±0.03mm, preventing bottom failure in high-pressure environments.
Surface Protection: The die components are treated with TD (Thermal Diffusion) coating to eliminate "pick-up" or galling marks on premium stainless steel.
Optimized Beat-Rate for Global Exporters
Reliability in the press shop is non-negotiable for high-volume kitchenware orders. This Deep Drawing Bowl Tooling is equipped with rapid-response nitrogen gas springs to provide constant pressure throughout the stroke. This results in a cleaner trim and a more stable flange, significantly reducing the need for secondary manual correction. Whether you are fabricating professional chef bowls or stackable industrial pails, our tooling delivers the repeatability required for automated 24/7 production lines.
| Technical Feature | Specification Detail |
| Tooling Configuration | Double-Action Drawing Die / Combination Die |
| Max Draw Depth | Up to 1.5x Diameter (Material Dependent) |
| Insert Hardness | HRC 62-64 (Vacuum Quenched) |
| Lubrication Compatibility | Optimized for Emulsion or Synthetic Oils |
| Ejection System | Pneumatic or Spring-Loaded Ejector |
