1. Engineering & Technical Product Description
Built to exceed strict AS9100 and ISO 13485 quality standards, our custom stamping die solutions specialize in challenging geometry forming for aerospace brackets, medical surgical instruments, and defense enclosures. Engineered with premium powder-metallurgy tool steels and processed via 5-axis CNC high-speed milling, this custom tooling system delivers tight dimensional tolerance control without stress-induced material warping.
2. Operational Specification Matrix
| Technical Metric | Medical Precision Grade | Aerospace Heavy Structural Grade |
|
Material Capability |
Titanium Grade 5 / Stainless 316L (0.15 - 1.0mm) |
High-Strength Aluminum / Inconel Alloys (1.2 - 4.5mm) |
|
Machining Clearance Precision |
±0.003 mm Range |
±0.010 mm Range |
|
Die Base Material Grade |
Pre-Hardened Tool Steel (SS410 / S50C) |
High-Yield Stress Forged Steel Plates |
|
Punch Surface Coating Option |
Diamond-Like Carbon (DLC) / PVD TiN |
Multi-layer AlCrN / CVD Coating |
|
Geometric Concentricity |
Within 0.002 mm |
Within 0.008 mm |
|
Expected Production Tooling Life |
3,000,000 Strokes |
1,000,000 to 2,500,000 Strokes |
3. Core Advantage & Process Innovations
5-Axis High-Speed CNC Surface Contouring: Die cavities and complex 3D punch profiles are machined directly on 5-axis German CNC centers, achieving smooth mirror surface finishes without localized heat distortion.
Stress-Relief Cryogenic Post-Processing: All custom-formed punch inserts undergo multi-stage deep cryogenic freezing to eliminate internal residual stress, preventing deformation when stamping hard aerospace alloys.
Sensor-Guided In-Die Quality Monitoring: Integrated with piezoelectric force transducers and laser displacement detectors to monitor forming pressure and material seat alignment during every stroke.
4. Frequently Asked Questions (FAQ)
Q1: How do you handle custom stamping die development for proprietary non-standard drawings?
A: We execute strict Non-Disclosure Agreements (NDAs) prior to file review. Our engineering team conducts full DFM (Design for Manufacturing) and Moldflow/Forming analyses, providing detailed 3D step files and T1 inspection plans for client sign-off.
Q2: Can your custom dies handle difficult materials like Titanium Grade 5 or Inconel alloys?
A: Yes. We utilize powder metallurgy steel punches (ASP-60 / CPM-10V) combined with specialized AlCrN anti-wear coatings to withstand extreme shear pressures without punch chipping or galling.
Q3: What quality certificates are provided with the completed custom tool assembly?
A: Every die ships with a complete validation package, including CMM inspection certificates, raw material mill test reports, heat treatment hardness certifications, and sample trial inspection reports.
Q4: What is the typical lead time for custom prototype dies versus production die sets?
A: Prototype quick-turn dies take approximately 15 to 20 working days, while full-scale multi-station production dies take 30 to 40 working days depending on part complexity.
