Heavy-Duty Metal Stamping Mold For Precision Sheet Components

Product Overview Achieve flawless sheet metal fabrication with our industrial-grade cold stamping mold systems. Engineered for high-volume presses, this tooling configuration incorporates state-of-the-art wear-compensating geometries and robust guide systems to sustain rigid concentricity....

Send Inquiry

Product Overview

Achieve flawless sheet metal fabrication with our industrial-grade cold stamping mold systems. Engineered for high-volume presses, this tooling configuration incorporates state-of-the-art wear-compensating geometries and robust guide systems to sustain rigid concentricity. Whether managing complex contours or deep drawing profiles, our manufacturing setup maintains tight linear tolerances over extended duty cycles.

Technical Specifications

Performance Category	Technical Parameters
Die Classification	Single Stage / Compound / Draw Die
Base Plate Steel	A3, S45C, Cast Iron (FC250)
Active Insert Material	Cr12MoV, DC53, SKH-9, Tungsten Alloy
Dimensional Tolerance	±0.005 mm to ±0.01 mm
Designed Die Life	800,000 to 2,500,000 runs
Sheet Thickness Range	0.5 mm - 8.0 mm
Raw Material Comp.	Carbon Steel, Aluminum, Brass, HRC Sheet
Surface Solidification	PVD Coating, Cr Plating, Hardening
Production Schedule	35 - 50 Calendar Days
Engineering Formats	STEP, DXF, IGS, DWG

Structural & Mechanical Enhancements

Friction-Reducing Metallurgy: Working punches are treated with advanced physical vapor deposition (PVD) layers, drastically lowering drag and heat buildup during fast cycling.

Elastic Blank-Holding Forces: Integrated gas springs and specialized polyurethane cushions stabilize sheet clamping pressure, preventing wrinkles and surface tearing.

Fool-Proof Alignment Systems: Precision guide pillars coupled with ball cages prevent misalignment during extreme eccentric loading on heavy-duty mechanical presses.

Modular Maintenance Access: All critical shearing and bending segments use a quick-change pocket design, reducing line stoppage for routine grinding or replacement.

Primary Commercial Operations

Our versatile mold platforms support a diverse range of heavy industrial fabrications, including structural chassis elements for logistics machinery, decorative housing panels for consumer appliances, and high-strength framing plates for infrastructure projects.
